CAMERA
| Image Sensor | 2MP CMOS Image Sensor |
| Signal System | PAL/NTSC |
| Frame Rate | PAL: 1080p@25fps; NTSC: 1080p@30fps |
| Effective Pixels | 1920 (H) ×1080 (V) |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Time | 1/25(1/30) s to 1/50,000 s |
| Lens | 2.8 mm, 3.6 mm, 6 mm optional |
| Angle of View | 103 ° (2.8 mm), 82.2 ° (3.6 mm), 54 ° (6 mm) |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1080p@25fps/1080p@30fps |
| S/N Ratio | ＞62dB |
MENU
| AGC | Low/middle/high |
| Day/Night Mode | Smart/color/BW(Black and White) |
| Backlight Compensation | Yes |
| DWDR | Yes |
| Language | English, Chinese |
| Functions | Brightness, Sharpness, DNR, Mirror |
INTERFACE
| Video Output | 1 HD analog output |
GENERAL
| Working | -20 °C - 45 °C (-4 °F - 113 °F) |
| Temperature/Humidity | Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC ±15% |
| Power Consumption | Max. 4W |
| Material | Plastic |
| Protection Level | IP66 |
| IR Range | Up to 20m |
| Dimension | Φ89.5 × 69.8 mm(Φ3.52” × 2.75”) |
| Weight | Approx. 280g |
